200-9 Nissei Vertical Injection Molding Machine '96

200-9 Nissei Vertical Injection Molding Machine '96

Have one to sell?
(561) 953-9100
sales@machinerycenter.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
Injection Molders - Vertical Type
Manufacturer:
NISSEI
Model:
TD200-36ASE
Year:
1996
Stock #:
18648
Status:
For Sale

Description

200-9 Nissei Vertical Injection Molding Machine '96

Tonnage200200
Shot99
Platen Size32.48" x 32.48"32.48" x 32.48"
Daylight (Max)29.53"29.53"
Mold Height (Min)13.8"13.8"
Ejector Stroke3.15"3.15"
Ejector Force4.35 Ton4.35 Ton
Clamp Stroke15.75"15.75"
Injection Force33.7 Ton33.7 Ton
Screw Stroke7.06"7.06"
Voltage460460
ControlNC9000GNC9000G
Dimensions14'11" L x 6'4" W x 10'6"H / Machine Floor Space: 13'L x 5'5"W14'11" L x 6'4" W x 10'6"H / Machine Floor Space: 13'L x 5'5"W

Injection Capacity: 255(PS) g/shot
Plasticizing Rate: 59 (PS) kg/hour
Injection Pressure: 2115 kg/cm (squared)
Injection Rate: 132 cm(cubed)/sec
Screw Speeds: 0-174 (low torque) 0-125 (high torque)
Nozzle Touch Force: 3.4 Tons
Parting Line: 7.8" x 11.8"
Distance Between Rods: 22.4" x 22.4"
Mold Open Force: 9.4 Tons
Max. Line Pressure: 140kg/cm (squared)
Pump-Elec Motor: 22kw/4 pole (30HP)
Heaters: 12.26 kw
Hydraulic Oil Req.: 171.7 Gallons

9 Oz. Injection Unit
Extra I/O For Robot Interface
Top Side Ejection
Special Core Pull
Spirex "A" Screw for Surlyn
RS232 Port
