1320 Ton, 218 Oz. MIR Injection Molding Machine '99

Name: Machinery Center, Inc.
Address: PO Box 812222,, Boca Raton, FL, 33481, US
Telephone: (561) 953-9100

Have one to sell?

$0.00 USD

ConditionUsed

Quantity

1 available

Have one to sell?

Overview

Type:

Injection Molders 901 Ton & Over

Manufacturer:

Model:

RMPE 1200/6200

Year:

1999

Stock #:

24798

Status:

For Sale

1320 Ton, 218 Oz. MIR Injection Molding Machine '99

ImperialMetric

Year	1999	1999
Tonnage	1320	1320
Shot Size	218	218
Platen Size	67.32" x 67.32"	67.32" x 67.32"
Tie Bar Spacing	44.00" x 44.00"	44.00" x 44.00"
Mold Height (Min)	13.78"	13.78"
Mold Height (Max)	43.31"	43.31"
Daylight	96.46"	96.46"
Screw Diameter	130mm	130mm
Core Pull	Yes	Yes
Control	Siemens S5 Control	Siemens S5 Control
Dimensions	Machine Dimensions (Overall): 519.7"L x 102.4"W x 103"H	Machine Dimensions (Overall): 519.7"L x 102.4"W x 103"H
Weight	Clamp Weight: 101,344 Lbs. / injection Unit Weight: 52,875 Lbs.	Clamp Weight: 101,344 Lbs. / injection Unit Weight: 52,875 Lbs.

Moving Platen Stroke: 53.15"
Tie Rod Diameter: 8.66"
Injection Rate with Accumulator: 3700 cm3/sec

218 Oz Injection Unit
Electric Screw Drive
Hydraulic Knockouts
Single Core Pull on Stationary Platen
Air Eject
Accumulator Package - 8 bottles
