330 Ton, 8 Oz. + 1 Oz. Cincinnati Powerline Two-Shot Injection Molding Machine '03
Have one to sell?
ConditionUsed
1 available
$119,500.00 USD
330 Ton, 8 Oz. + 1 Oz. Cincinnati Powerline Two-Shot Injection Molding Machine '03
8 Oz. + 1 Oz. Injection Unit
Bimetallic X102 Barrels on both units
Colmonoy 56 Feedscrew
Extended Daylight (406.4mm)
Sprue Break, Stack Mold, Hydr. Pull-in System
Closed Loop Feed Throat Control
Mallard Screw Tip, 4-piece spinner type non-return
Valve
3 Stage Air Eject
Auto Lubrication System
Wired for Core Pull
330 Ton, 8 Oz. + 1 Oz. Cincinnati Powerline Two-Shot Injection Molding Machine '03
Imperial
| Year | 2003 |
| Tonnage | 330 |
| Shot Size | 8 |
| Platen Size | 40.55" x 40.55" |
| Tie Bar Spacing | 27.60" x 27.60" |
| Daylight (Min/Max) | 50" Max |
| Mold Height (Min) | 7.9" |
| Mold Height (Max) | 27.60" |
| Clamp Stroke | 23.62" |
| Ejector Stroke | 7.87" |
| Control | Xtreem ST |
8 Oz. + 1 Oz. Injection Unit
Bimetallic X102 Barrels on both units
Colmonoy 56 Feedscrew
Extended Daylight (406.4mm)
Sprue Break, Stack Mold, Hydr. Pull-in System
Closed Loop Feed Throat Control
Mallard Screw Tip, 4-piece spinner type non-return
Valve
3 Stage Air Eject
Auto Lubrication System
Wired for Core Pull
