Hyundiai Wia CNC Turning Center '18

Hyundiai Wia CNC Turning Center '18

Have one to sell?
(561) 953-9100
sales@machinerycenter.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC Lathes
Manufacturer:
HYUNDAI
Model:
L400MC
Year:
2018
Stock #:
27669
Status:
For Sale

Description

Hyundiai Wia CNC Turning Center '18

Swing Over Bed30.7"30.7"
Swing Over Carriage21.1"21.1"
Max. Turning Diameter22"22"
Max. Turning Length46.5"46.5"
Live Milling Motor4,000 RPM4,000 RPM
Spindle Speed(2 Speed Geared): 2,000 RPM(2 Speed Geared): 2,000 RPM
Turret1212
Spindle Bore/Bar Capacity5.1"/4.6"5.1"/4.6"
ControlFanuc 32iB CNC ControlFanuc 32iB CNC Control
DimensionsFloor Space: 165" X 87" X 85" HFloor Space: 165" X 87" X 85" H
Weight24,200 Lbs.24,200 Lbs.

Chuck Size: 15"
C-Axis Indexing: 360 Degree
(0.001 Degree)
X-AXIS Travel: 12.8"
Z-AXIS Travel: 47.4"
Main Motor: 50 HP
Spindle Nose: A2-11
Voltage: 220/3/60
Positions

Live Milling:
Milling Tool Motor: 10 HP

Tailstock Taper: MT5
Tailstock Quill Diameter / Travel: 5.9"/5.2"
Tailstock Travel: 43.3"

Only 513 Cutting Hours. Like New Condition

- Auto Q-Setter (Tool Setter)
- 15" 3-Jaw Hydraulic Chuck
- Chip Conveyor
- Programmable Tailstock
- Box Ways For All Axes
- 5 Live Holders
