1000 Ton, 209.2 Oz. Engel Injection Molding Machine '00

209.2 Oz. Injection Unit
Standard Paint m/c it green (EC#5007) & black (EC5001) clamp assy Pump/motor platform-lrg mcs only
3. Levelling & vibration mounts
Bilingual warning labels in English & French (ipos)
Auxiliary bypass oil filtration.
SPI Safety key switch.
4 x air blow off with timer & ½" 3-way valve 2 on stationary & 2 on moving platen.
Hydraulically actuated mold valve gate shut-off via accumulator.
Double corepull/rack & pinion unscrewing.
Platens prepared for retrofit of QMM.
Ultramax bi-metallic barrel (in place of standard)
Increased hydr. drive-improved plasticizing, faster speed/cycle.
Accu pig for incr inj speed c/w ind. Charg’ incl EOF-CC100 mcs.
24:1 ENGEL MeltPro Barrier screw 4140 base steel, Colmonoy #86 weld flight land, chrome
plated root and Pulsar mixer/adder (pos).
Power capacitor.
Mineral insulated heater bands.
Power conditioner for triacs.
Alarm bell and re-set switch.
2 x 115/1-60 (15 amps max.) Duplex outlet; 1 located on operator side of control panel location
“E”; 1 located on operator side gate assembly.
230/3/60 - 30 amp Hubbel #2720 outlet located on right hand of AC panel, location “F”.
CC100 Microprocessor.
CC100 Level 2 Software.
CC100 Microgplast/Microflow Processing Software.
CC100 Micrograph Plus.
CC100 Process Data - Graphics and Reports.
Ejector back confirm’n input signal (does not incl, limit switch.
16 x CC100 PID mold temperature control zones.
Re. option # 1134, 15 amps each, multi-plug DME located inside gate on non-operator side.
Closed loop feed throat cooling control:
CC100 8 Zone temperature control card.
Engel RC100 robot interface includes cycle start button.
Conversion from English to French text - instant.
Robot operator side deposit.
Special key switch (per confirmation 12/8/00).
Extended ejector plate to handle ejectors at 508mm from the center.
Grease nipple required on extended ejector plate at each guide bar.
