1200 Ton, 196 Oz. LS MTron Injection Molding Machine

1200 Ton, 196 Oz. LS MTron Injection Molding Machine

Have one to sell?
(561) 953-9100
sales@machinerycenter.com
ConditionUsed
1 available
Have one to sell?

Document (1)

28232-Options.pdf

Overview

Type:
Injection Molders 901 Ton & Over
Manufacturer:
LS MTron
Model:
The ONE 1200 i101 "B"
Stock #:
28232
Status:
For Sale

Description

1200 Ton, 196 Oz. LS MTron Injection Molding Machine
Model: The ONE 1200 i101 "B"

Tonnage12001200
Shot Size196196
Platen Size76.8" x 65"76.8" x 65"
Tie Bar Spacing55.9" x 45.3"55.9" x 45.3"
Mold Height (Min)23.6"23.6"
Mold Height (Max)51.2"51.2"
Daylight94.5"94.5"
Ejector Stroke11.8"11.8"
Ejector Force24.5 Ton24.5 Ton
Screw Diameter4.5"4.5"
Voltage480/3/60480/3/60
Core PullYesYes
ControlKEBA Touchscreen (15")KEBA Touchscreen (15")
Dimensions30.8'L x 11.5'W x 8.2'H30.8'L x 11.5'W x 8.2'H
Weight81,571 Lbs. + 22,046 Lbs.81,571 Lbs. + 22,046 Lbs.

Max Mold Weight: 46,297 Lbs.
Max Injection Pressure: 23940 psi
Die Plate Dimensions: 76.8" x 64.9"
Opening Stroke: 43.3"(Min) x 70.9"(Max)

196 Oz. Injection Unit
Hydraulic Dual (1) Moving, (1) Stationary
Core Pull Single A or C & Dual A or C
Mold Open & Close During Charging Electric Screw Drive Hydraulic Shut off nozzle
Euromap 67 Robot Interface
Air Eject (2) Stationary & Moving
Horizontal & Vertical T-Slots
Water Cooling manifold (12 Zones-in, 12 Zones-out) 1-Stationary, 1-Moving Platen
