Overview

Type:

Injection Molders 601 To 700 Ton

Manufacturer:

Model:

FVX560 III - 310L

Condition:

Excellent

Year:

2017

Stock #:

28542

Status:

For Sale

Description

618 Ton, 132 Oz. Nissei Hybrid Injection Molding Machine '17
Model: FVX560III-310L
Hours: 23,122

ImperialMetric

Year	2017	2017
Tonnage	618	618
Shot Size	132	132
Platen Size	53.5" × 53.5"	53.5" × 53.5"
Tie Bar Spacing	38.2" × 38.2"	38.2" × 38.2"
Mold Height (Min)	15.7"	15.7"
Mold Height (Max)	35.4"	35.4"
Daylight	71.3"	71.3"
Ejector Stroke	7.1"	7.1"
Clamp Stroke	35.4"	35.4"
Screw Diameter	3.5"	3.5"
Voltage	400 Volt/3 Phase	400 Volt/3 Phase
Core Pull	Yes	Yes
Control	Tact IV	Tact IV
Horz/Vert	Horz	Horz
Dimensions	Clamp: 17.6" x 6.9" x 7.2" / Inj. Unit: 14.6" x 5.11" x 6.11"	Clamp: 17.6" x 6.9" x 7.2" / Inj. Unit: 14.6" x 5.11" x 6.11"
Weight	Clamp: 45000 Lbs./Inj. Unit: 18,000 Lbs	Clamp: 45000 Lbs./Inj. Unit: 18,000 Lbs

132 Oz. Injection Unit
Core Pull
Air Blow
Air Blast
